2X Series Oil Sealed Rotary Vane Vacuum Pump 0.37kw-5.5kw Non Corrosive

Description : 2X series rotary vane vacuum pump-Rotary Vane Vacuum Pump

Usage : Air Pump,Water,Single-stage water ring vacuum pump,oil,food

Power : Electric,4-185kW,Pneumatic,4KW,180 W

Pressure : Low Pressure,High Pressure,0.098 Mpa,Other,3300pa

Fuel : Electric,Diesel,vacuum pump oil,water,Power

Application : vacuum pumps for chemical applications,Air and gas,air exhaust of refrigeration equipment,vacuum packing,vacuum forming

Structure : Multistage Pump,Single-stage Pump,Double-stage Pump,Single-stage water ring vacuum pump,Water ring

Theory : Vacuum Pump,Rotary Pump,Centrifugal Pump,water ring,Single-stage water ring vacuum pump

Standard or nonstandard : Standard

Voltage : 380v,415v,220V/380V,460v,Requirements

Warranty : One Year,1 Year Warranty(except Wearing Parts),12 Months,for quality problem,guarantee to repair or replace within one year

Place of Origin : China

Certification : ISO9001

MOQ : 1 set

Price : Negotiable

Packaging Details : Wooden case

Delivery Time : 1-15 days

Payment Terms : T/T

Supply Ability : 50000set/Year

Contact Now

2X series rotary vane vacuum pump-Rotary Vane Vacuum Pump

2X series rotary vane vacuum pump is the basic equipment used to extract gas from sealed containers to obtain vacuum. This series of vacuum pumps can be used alone, or as a backing pump for booster pumps, diffusion pump molecular pumps and bowl pumps. Vacuum coating, vacuum heat treatment, vacuum pouring, exhaust of electronic tubes, light bulbs, thermos bottles, etc. Medical and sanitation and laboratories can also be equipped with this pump. Note: The pump is not easy to pump out the gas containing too much oxygen, harmful, explosive, corrosive to metal, chemically reactive to vacuum oil, and containing particles of dust, nor can it be used to pump gas from one container to another. When the transfer pump is equipped with an aeration valve, it can pump an appropriate amount of condensable gas.

model	2X-2	2X-4	2X-8	2X-15	2X-30A	2X-70A
ultimate partial pressure(Pa)	≤6x10-2
ultimate total pressure(Pa)	≤1
Pumping rate(L／s)	2	4	8	15	30	70
Motor Power(kW)	0.37	0.55	1.1	2.2	3	5.5
Pump shaft speed(r／min)	610	610	590	320	450	420
noise dB(A)	65		70		75
Air inlet diameter(mm)	25	25	40	36	65	80
cooling method	natural air cooling				water cooling
temperature rise(℃)	<40
Oil quantity(L)	0.35	0.55	0.6	4.2	3.2	6
weight( including motor)(Kg)	40	09	78	128	231	375
